Creating a detailed longitudinal section for a Drift

2022-07-18

By Mohamed Zaki

Mohamed Zaki

Mohamed Zaki has an undergraduate degree in Mining Engineering CO-OP from McGill University. With an opportunity to do 3 research studies with excellent professors from McGill University and experience in open-pit mining, he developed an interest in analyzing data using powerful programs. Upon joining the Promine team, Mohamed worked as a Quality Assurance & Support Specialist, then obtained a position as a Sales Specialist. A few months later, he took the role of a Marketing manager to promote the professional image of Promine. Currently, Mohamed is the Director of Business Development of EMEA at Promine.

Inside the Drift design module, we have many commands to create drifts, annotate them, create schedules, add ramps and many more tools. We also have a complete set of commands for creating longitudinal sections across drifts, ramps, cross sections or any other type of development that has a centerline. We have the option to create this section automatically or configure it manually and to add stations, points and project surrounding developments. This helps us get a better understanding of our developments with using a few commands and displaying the information with a few clicks. 
