Design a drill pattern using remote drilling in AutoCAD

2022-07-18

By Mohamed Zaki

Mohamed Zaki

Mohamed Zaki has an undergraduate degree in Mining Engineering CO-OP from McGill University. With an opportunity to do 3 research studies with excellent professors from McGill University and experience in open-pit mining, he developed an interest in analyzing data using powerful programs. Upon joining the Promine team, Mohamed worked as a Quality Assurance & Support Specialist, then obtained a position as a Sales Specialist. A few months later, he took the role of a Marketing manager to promote the professional image of Promine. Currently, Mohamed is the Director of Business Development of EMEA at Promine.

The Drill/Blast Underground module gives you the option to design remote drilling polylines when setting up your drill pattern on a section. From the module options, select the option to insert X marks at the remote drilling intersections and to insert the distances measurements in the report. This will allow you to know quickly when to start your remote drilling; thus, increasing your work efficiency. 
